LS-F6 Gift Rigid Box Forming Machine For Perfume Box

For the LS-F6 perfume box, a rigid box making machine is used to fold glued paper into a glued box. It can complete side wrapping, edge folding, tucking and air compression at the same time, which is suitable for wrapping all kinds of rigid boxes, such as shoe boxes, gift boxes, mobile phone boxes, perfume boxes and more.
  • LS-F6

  • Longxingsheng


Air Tac brand pneumatic components, durable. Imported double high-precision guide, stable and works continuously. Double safety devices ensure safety. A lead screw was used to control the movement of the working seat, easy and convenient. Mass production.

The machine is an ideal automatic tool for processing hardcover and rigid boxes. The inner box and wrapping paper are carefully placed on the assembly line by hand, and the placed paper box is placed in the wooden mold of the machine. The machine works automatically, and the box gluing, edge bending and bubble pressing will be completed at the same time.

Up to 30 hardcover boxes can be produced per minute, which greatly increases the efficiency of hardcover box production and saves production costs. Because each action is mechanical to complete, standardized production greatly improves product quality.

Box size (max)L460*W380*H120mm L650*W450*H150mm
Box size (min)L80*W65*H10mm L100*W80*H15mm
Motor power2.5kw/220v 2.5kw/220v
Air pressure10L/min 0.6mpa 10L/min 0.6mpa
Working speed≤30pcs/min
DimensionL1220*W960*H2100mm L1220*W960*H2100mm
Weight950kg 950kg
